AutoCAD 2019 – There can be only ONE….

For those of you old enough to remember the movie Highlander, when the Quickening starts there can be only one. Apart from the stunning Queen soundtrack, it was a great movie, and Connor MacLeod (actor Christopher Lambert) of the clan MacLeod was THE one, combined with incredible support from famous co-star Sean Connery as Juan Sanchez Villa-Lobos Ramirez, who (unfortunately) does lose his head.

As they say in the movie (and the Queen song), it’s a kind of magic……

(For those of you that like a bit of Freddie and the band Queen, here’s the link to the album, A Kind Of Magic – CLICK HERE).

So, here we go, why ONE AutoCAD?

ONE AutoCAD

In the world of the new version of AutoCAD, AutoCAD 2019, we have only ONE too. When you subscribe to AutoCAD 2019, you get ONE subscription, but the many faces of AutoCAD; Architecture, Electrical, Mechanical, MEP, and various other flavors. This not only gives you a specialized AutoCAD by allowing you to work in various disciplines and verticals, but also gives you various workflow improvements too. However, Civil 3D has been omitted from the ONE AutoCAD intentionally, and I am sure Autodesk have their reasons for that.

Design Toolsets

When you log in to your account portal, you will see that it has changed and the view of your subscribed AutoCAD you get now is one (pardon the pun) of many, listing all the products under your main AutoCAD subscription. You will also find that the view of AutoCAD in your Autodesk Desktop App has changed as well.

What’s nice here is that you can select all the AutoCADs to be trialed or you can select individual flavors of AutoCAD to be trialed. This is especially advantageous if you are already a vanilla AutoCAD user and want to test a specific flavor of AutoCAD to see if it fulfills your needs and requirements. For those of you that just want all the flavors, but for one price, it is a great move by Autodesk also.

On your desktop, each flavour of AutoCAD will still have its own individual icon (just to clutter your desktop, I guess…an untidy desktop is a sign of a great mind, right?), plus, there will be no change to the DWG Launcher. You know, that little gizmo in Windows that allows you to open all DWG files using AutoCAD as the preferred application to do so.

Web and Mobile

There have been some great improvements in AutoCAD 2019. One of these is the ability to save your desktop AutoCAD designs directly to AutoCAD Web and AutoCAD Mobile. If you go to the Quick Access Toolbar (top left of the desktop AutoCAD application window), you will see the new icons there that not only provide you with the facility to save to web and mobile but also go directly to those saved cloud-based designs and open them directly in the AutoCAD desktop again as well. This is also available in the AutoCAD application menu. These cloud-based files go to A360 Drive in the usual way.

Save to Web and Mobile

So, what’s new with AutoCAD Web and Mobile then? Well, AutoCAD Web is much enhanced to give a highly sophisticated browser-based AutoCAD interface, that is quicker and faster. I won’t bore you with the techie stuff, but suffice to say, you will be using the equivalent AutoCAD executable (EXE) in your browser, the same as you would be on your desktop. This makes for a much-needed boost to what was (sometimes) quite a jerky, laggy web-based application in the past.

You will find AutoCAD Web at web.autocad.com and if you are using the subscription version (it comes with full AutoCAD), you get a great new command panel incorporating some of the more familiar AutoCAD drafting icons, that even have a preview, just like desktop AutoCAD.

AutoCAD Web

What’s also new is the referencing capability of AutoCAD Web. You can add reference drawings (XREFs) at your leisure, and if they are saved in the cloud in the same location as the host drawing, using the save to web and mobile options in your desktop AutoCAD, they will operate in the same way as relative XREFs that you might use locally.

Something I love (yes, love, not just like) is that you now have the native AutoCAD window and crossing selection tools in AutoCAD Web. They work in the same way as your desktop AutoCAD and provide a rounder user experience. We have grown used to these methods of selection, and it is great to see Autodesk taking the desktop user experience tools in to the web-based version. It is by no way perfect yet, but I can see AutoCAD Web getting to a point where your AutoCAD desktop will become fully mobile. The hardware is there now; such as the Apple iPad Pro and the Microsoft Surface Pro, that have the grunt under the hood to run AutoCAD Web and AutoCAD Mobile well.

What makes AutoCAD Web even more like desktop AutoCAD is that there are even some keyboard shortcuts included as well. I mean, come on, who doesn’t love a keyboard shortcut or two? Trust me, as a seasoned AutoCAD user (thirty years this year), I am a big fan of keyboard shortcuts!

Overall, though, I have to say that I am mightily impressed with the new AutoCAD Web. It has been well thought out and gives you a great browser-based AutoCAD experience that relates back to your desktop AutoCAD this time. And with regular updates promised by Autodesk, I can see AutoCAD Web developing at a quick pace to bring you a much slicker experience with AutoCAD Web on the web. Did I say ‘web’ enough there for you?

New Features and Enhancements

Back to the desktop AutoCAD now. Autodesk have added a couple of new features to AutoCAD 2019.

On the new Collaborate tab in the AutoCAD ribbon, you will find the DWG Compare command. This new feature is, quite simply, excellent. I wish I’d had it years ago. You can now compare two separate DWG files and AutoCAD creates a new comparison DWG file, highlighting any differences between the two compared drawings, using colors and revision clouds, providing tools to iterate between each difference and zoom in to each difference automatically.

DWG Compare

Another great new feature on the Collaborate tab is Shared Views. You can upload your designs directly to the web in to the Autodesk Viewer, a cloud-based viewer. You can invite other collaborators to view your design by way of a private URL that can be emailed to the respective team members. Also, in the Autodesk Viewer, there is a Comment feed that allows all invited users to comment on the shared design and link their comments to the design as well.

Shared Views

You may also notice that there are enhanced icons in AutoCAD 2019 that look different too. To bring AutoCAD 2019 in line with the 4K monitors out there, over 5000 icons have been revamped and redesigned in the ribbon, status bar and application menu. They provide a slick, professional look to AutoCAD that looks modern and clean. The cartoony icons now have a tidier, minimalist look that I have to say I prefer.

Enhanced Icons

Conclusions

Autodesk are taking AutoCAD to a new level with this release. Not only are you getting numerous flavors of AutoCAD as one subscription package, but you’re also getting a great web-based offering too, along with some cool new features and enhancements in the desktop application, with cool command icons. And don’t forget, you STILL get seamless DWG compatibility with AutoCAD for Mac too.

Overall, a nice AutoCAD offering from Autodesk, and I love the new AutoCAD Web, but I would still like to see more new features and enhancements in the desktop AutoCAD, especially on the new Collaborate tab. Collaboration is becoming more and more prevalent in this age of email, webmail and the cloud, and I hope to see Autodesk take advantage of that movement to make AutoCAD even more mobile in the future.

Happy AutoCAD’ing!

SCB.

PS – As some of you may know, I provide online AutoCAD learning content over at LinkedIn Learning and Lynda.com. You’ll find all the new AutoCAD 2019 Essential Training material below: –

LinkedIn Learning – CLICK HERE

Lynda.com – CLICK HERE
